      Interior Full Color LED Display - Specifications

      Technical Details


      Model P1.9 P2.6 P2.9 P3.9
      Pixel Pitch 1.953 mm 2.604 mm 2.967 mm 3.906 mm
      LED Type SMD1515 SMD1515 SMD2020 SMD2020
      Module Resolution (dots) 128 x 128  96 x 96  84 x 84  64 x 64
      Driving Mode 1/32 scan 1/32 scan 1/28 scan 1/16 scan
      Module Size 250mm x 250mm
      Cabinet Sizes (WxH)

      1000x250 mm
      750x250 mm
      500x500 mm
      500x250 mm
      250x250 mm
      Pixel Density (dots/m2) 262,144  147,456 112,896  65,536
      Viewing Distance ≥1.9m ≥2.6m ≥2.9m ≥3.9m
      Brightness ≥800 nits
      Protection Level IP43
      Refresh Rate 3840 Hz
      Grey Scale 13 bits - 16 bits
      Best Viewing Angle V:160˚/H:160˚
      Max Power Consumption (w/m2) 600  550  400 430
      Avg Power Consumption (w/m2) 180 160 120 125
      Input Voltage AC110V-240V @ 50 Hz-60Hz
      Operating Temperature/Humidity -20˚-50˚C / 10% - 90% RH
      Cabinet Material Die Cast Illuminum
